ISUZU NPR/ELF 700P 8CBM Back Loading Waste Collection Truck For Sale
Order(MOQ):
1Factory Outlet ISUZU NPR 8CBM Rear Load Rubbish Collection Truck
ISUZU 6 wheels 8CBM garbage compressor truck (also called ISUZU garbage compactor truck, ISUZU hydraulic garbage compression truck, ISUZU refuse compactor truck ) suitable for the garbage collection and transportation in good conditions places, such as urban and rural streets, large factories, residential areas and school.
100% custom-made
|
|
3 cbm to 22 cbm available
|
|
Short delivery time 7~30 days
|
|
Easy operation & Easy maintenance
|
|
15 years spare parts & Technical support
|
PowerStar Trucks Industry Co., Limited |
|||
Product Name |
ISUZU 700P refuse compactor truck |
||
Vehicle Brand Series |
ISUZU |
||
Vehicle Model |
PST5100ZYS |
||
Production Time |
25 days |
||
Chassis parameters |
Overall dimensions |
mm |
7400*2200*2600 |
Gross weight |
kg |
10,000 |
|
Kerb weight |
5,600 |
||
Wheelbase |
mm |
4,175 |
|
Driving type |
4*2 |
||
Chassis model |
ISUZU ELF 700P |
||
Tire size |
235/75R17.5 |
||
Number of Tires |
6+1 |
||
Passengers in cab |
3 |
||
Engine |
Engine model |
4HK1-TC51 |
|
Type of fuel |
Diesel |
||
Power |
190HP |
||
Max speed |
Km/h |
95 |
|
Emission standard |
EURO 5,6 |
||
Compactor performance |
Compactor Body |
8 CBM |
|
Body Material |
Weather Resisting Steel |
||
Compressing Ration |
≥ 1:3.4 |
||
Dust Bin Lifter |
120 lt. - 240 lt- Two bins |
||
Optional 1100 lt,660 lt |
|||
Loading Cycle Time |
15 ~ 20 sec |
||
Discharging Time |
10 ~18 sec |
||
Discharging system |
Horizontal ejection |
||
Waste Water Tank |
200L |
||
Operation |
Siemens Automatic-PLC system |
||
Control Panel |
English |
||
Foot Stands |
2 sets with handle |
||
Painting |
Two primers, and one final paint coating |
||
Color & LOGO |
According to wish |
||
Factory standard |
“U” shape Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp, Working Lamp, Hand holds, Mudguards and rubber flaps... |
||
Documents |
English operation manual, Spare parts list, and all necessary export docs. |
||
Optional equipment |
1, Dust bin lifting system (with any option) 2, Rear vision camera 3, Italy imported multi-way valve 4, Optional stainless steel waste water tank |
Key words: ISUZU 700P Trash Compactor Truck, ISUZU Rear Load Waste Truck, ISUZU Compressed Refuse Truck, ISUZU 4x2 Refuse Compressor Truck
