2T Isuzu chassis straight arm telescopic truck crane/truck with crane
Order(MOQ):
12T Isuzu chassis straight arm telescopic truck crane/truck with crane
Durable 2T Hydraulic Driver Lorry Mounted Crane, Cargo Crane Truck
Description:
Knuckle boom truck mounted crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.
Knuckle boom crane SQ2ZK1 is used for lifting 2tons, moment is 3.2T.M.
Applications:
It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.
Knuckle boom cranes can be configured to do just about any job imaginable, from delivering products to cleaning up debris after the job is done.
Specifications:
Model |
SQ2ZK1 |
Unit |
Max Lifting Moment |
3.2 |
t.m |
Max Lifting Capacity |
2000 |
kg |
Recommend Power Needed At Recommend Oil Flow |
9 |
kw |
Max Oil Flow of Hydraulic System |
20 |
L/min |
Rated Pressure Of Hydraulic System |
20 |
MPa |
Oil Tank Capacity |
25 |
L |
Rotation Angle |
370 |
° |
Crane Weight |
608 |
kg |
Installation Space |
680 |
mm |
Choice of Chassis |
ISUZU | |
SQ2ZK1 Lifting capability diagram |
|||
Working radius (m) |
1.5 |
3.53 |
4.78 |
Lifting capacity (kg) |
2000 |
900 |
600 |
