140 Foot Bogie Flatbed Semi-trailer
| DIMENSIONS | ||
| Tare Weight | 7700kg | |
| Payload | 40000kg | |
| Total Weight | 47700kg | |
| Overall Length | 12620mm | |
| Overall Width | 2480mm | |
| Overall Height | 1530mm | |
| Wheel Track | 1850mm | |
| Wheelbase | 8025mm+1550mm | |
| STANDARD SPECIFICATION | ||
| Main Frame | Heavy duty and extra durability designed; Opting for high tensile steel Q345B,welded by automatic Submerged-Arc processes 500mmHeight I beam, Top Flange 14mm,width 140mm; Middle Flange 6mm ; Bottom Flange 16mm,width 140mm |
|
| Floor | Steel Sheet 3mm thickness | |
| Axle | 2 units of FUWA (brand) 13T axle | |
| Suspension | A couple of Two-axle mechancial suspension. | |
| Leaf Spring | Four sets of reliable local brand, 8-piece leaf spring,16x90mm | |
| King Pin | One unit of 2`` SAE bolted-in kingpin. | |
| Landing Gear | JOST-C200,Two-speed , manual operating, heavy duty landing gear | |
| Wheel Rim | 9 units of 8.25-22.5 rim. | |
| Tyre | 9 units of 11R22.5 tubeless tyre. | |
| Twist Lock | Twelve nos. of ISO twist lock for 2x20ft;1x40ft container, all the locks can be laid down. | |
| Spare Wheel Carrier | One set of spare wheel carrier including a riser. | |
| Pneumatic Braking System | One units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; one units of reliable local brand 40L air tank ; two units of reliable local brand standard coppery air-connector. | |
| Electrical System | One unit of JAEGER POWAY ,24V 7-pin ISO 1185 socket; Tail lamp with turn signal, brake light & reflector , Side lamp etc. One set of 6-core standard Cable. |
|
| Painting | Sand blasting processing clean rust 1 coat of anticorrosive primer 2 coats of finish urethane paint Color as customer choice |
|
| Accessory | One tooling box with a set of standard trailer tool | |
