The main function of the Isuzu hydraulic boom crane truck is to carry out cargo lifting and transportation. It is a common and important mechanical equipment used to carry and lift heavy objects on construction sites. The Isuzu hydraulic boom crane truck can be quickly set up on site and is capable of efficient lifting operations. The Isuzu hydraulic boom crane truck can provide a large amount of lifting force and working range to meet various lifting needs.
Isuzu hydraulic boom crane truck also called boom truck crane, mobile truck crane, telescopic straight boom crane, hydraulic arm crane for trucks,hydraulic crane telescopic boom,self loader truck with boom crane etc.
The optional tonnages include 2 tons, 3.2 tons, 4 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, 18 tons, 20 tons, 25 tons, 30 tons, etc. You can choose straight arm or folding arm crane. Isuzu hydraulic crane truck is composed of boom, turntable, frame, outriggers and other parts. The mechanical action of the truck crane is realized through the action of the mechanism of luffing, telescopic, slewing, hoisting, etc., and the lifting operation is realized through the combination of different actions.
Technical parameter of chassis |
|||
Chassis Brand |
ISUZU/NPR |
Color |
White or optional |
Engine |
Fuel Type |
Diesel |
|
Horse power |
139kw/190HP |
||
Displacement |
5193ml |
||
Engine Type |
4 cylinders in line,high pressure common rail,multi - stage jet |
||
Emission Standard |
Euro 6 |
||
Wheel Base(mm) |
4175 |
Driving type |
4x2 |
Type & Size of Tyre |
235/75R17.5 tire(6+1pcs) |
Gear Box |
ISUZU MLD 6 speed forward with 1 reverse, manual |
Brake |
Air brake |
Steering Wheel |
Left Hand Drive with power-assisted |
Technical parameter of crane(5T straight arm) |
|||
Crane model |
XCMG SQS125 |
Crane Type |
Telescopic boom crane |
Material |
High performance carbon steel |
Crane weight (KG) |
2260 |
Max. lifting weight(KG) |
5,000 |
Max. working height (m) |
12.5 |
Oil tank capacity (L) |
90 |
Max. Oil Flow of Hydraulic System |
32 L/min |
Max. working radius (m) |
11 |
Installation space(mm) |
900 |
Rotation angle |
360°, all rotation |
Boom No |
4 section |
Isuzu NPR hydraulic boom crane trucks are popular choices for various industries due to their durability, efficiency, and versatility. Isuzu hydraulic crane truckare equipped with a hydraulic boom crane, which allows for heavy lifting and transportation of goods. Common Isuzu hydraulic boom crane trucks have several key features that make them stand out in the market.
1. Isuzu hydraulic boom crane truck are known for their excellent lifting capacity.
Isuzu hydraulic boom crane truck are equipped with sturdy hydraulic cranes that can lift heavy loads with ease. The hydraulic system allows for smooth and precise control of the crane, making it easy to lift and move goods safely. The lifting capacity of Isuzu hydraulic boom crane truck varies depending on the model.
2. Isuzu truck mounted crane are designed for efficiency and ease of use.
Isuzu truck mounted crane are equipped with user-friendly controls that make operating the hydraulic crane simple for drivers. The crane can be easily maneuvered to lift and place loads in tight spaces, making it ideal for jobs that require precision and agility. Additionally, Isuzu truck mounted crane are built to withstand tough working conditions, ensuring reliable performance even in challenging environments.
3. Isuzu telescopic crane truck are known for their versatility.
Isuzu telescopic crane truck are often used in construction, logistics, and other industries where heavy lifting is required. The hydraulic crane can be easily mounted and dismounted from the truck, allowing for quick and efficient use of the vehicle for different tasks. Isuzu telescopic crane truck come in various sizes and configurations to suit different needs, making them a versatile choice for businesses looking to optimize their lifting capabilities.
In conclusion, Isuzu hydraulic boom crane trucks are common choices in the market due to their excellent lifting capacity, efficiency, and versatility. These trucks are reliable, durable, and easy to operate, making them ideal for businesses that require heavy lifting capabilities. With their sturdy hydraulic cranes, user-friendly controls, and versatile designs, Isuzu hydraulic boom crane trucks are a popular option for industries that require efficient and reliable transportation of goods.
