Isuzu water truck

With the continuous development and improvement of the urban environment, Isuzu water tank truck is a multi-functional watering tool widely used in urban environments. It is equipped with front and rear sprinklers, a working platform and a water cannon, and is equipped with functions such as water suction pipes and fire joints. This article will introduce the functions and usage instructions of Isuzu water tank truck in detail, and emphasize the requirements for water sources as well as daily maintenance and precautions.

1. Functions and related equipment of Isuzu water tank truck
The main function of Isuzu GIGA water tank truck is for greening spraying and environmental cleaning. It is equipped with duckbill nozzles or round nozzles and cylindrical sprinkler nozzles or shower nozzles. There is also a working platform at the front for operation and observation. In addition, Isuzu sprinkler trucks are also equipped with water cannons that can be used for long-distance flushing and cleaning. 8 additional nozzles can also be installed on the rear to provide a wider spray range and effect.
2. Special functions of Isuzu water tank truck
Isuzu water sprinkler truck is mainly used for greening and sanitation work in urban communities and factories. It uses a high-power dedicated sprinkler pump to ensure high-quality spraying effects. It can spray forward and backward, and also has a side spray (shower) function and a rear working platform. A greening sprinkler anti-aircraft gun is installed on the working platform, with adjustable functions of heavy rain, moderate rain, drizzle and mist spraying. In addition, Isuzu sprinkler trucks are equipped with ancillary equipment such as suction pipes, fire joints and gravity valves to provide comprehensive environmental protection and safety performance.

3. Operation of Isuzu water tank truck
The operating system of Isuzu water truck is mainly driven by the engine and the gearbox, and the sprinkler pump is driven by the power take-off on the gearbox. The sprinkler pump sprays the liquid in the tank through the pipe network.
1).Water absorption work. When performing water suction work, first park the Isuzu water wagon as close to the work site as possible. Then open the side door of the walking platform box, take out the water-absorbing hose, and swing it back to make sure there is no bending. Next, put the water-absorbing hose as deep into the water as possible, ensuring that the end of the pipe is always less than 300mm away from the liquid surface. Push the handle of the four-way valve until it is perpendicular to the ground. Then put the transmission into neutral, start the engine, and disengage the clutch. Pull the power take-off switch backward to put the power take-off into gear, and then the sprinkler pump starts running. During operation, the liquid level can be observed through the sight glass on the top of the rear head. When the liquid level reaches the middle of the sight glass, the driver should be notified and the water suction hose should be quickly pulled away from the water surface or the four-way valve should be closed. After putting away the hose, put it back into the walking box and close the side door. Finally, drive the sprinkler truck away from the pumping site.
2.) Spraying operations. When performing spraying operations, first pull the rear handle of the four-way valve parallel to the ground, and open the ball valve of the nozzle you want to use (front spray, rear spray, side spray, shower). Then start the engine, shift the transmission into the corresponding gear, and pull the power take-off switch back to shift into gear and take out power. Finally, the clutch is released, the sprinkler pump starts running, and spraying can begin. When the water in the tank is exhausted, the driver should push the power take-off control handle forward in time to disengage the gear. At this time, the sprinkler pump stops running.

4. Water source requirements and precautions
When using the Isuzu water wagon, you need to pay attention to the water source requirements. If you choose rivers, ponds, etc. as the water source, make sure that the end of the suction pipe is completely immersed in the water. In order to avoid inhaling stones, sediment and impurities, the end of the water suction pipe is generally equipped with a filter device. It is strictly forbidden to remove the filter device during the water absorption process. If the water source is shallow, you need to dig deep to absorb the water in advance to ensure that gas and debris will not be carried. In addition, different types of sprinkler trucks have different requirements for water sources. Clean water pumps require that there be no impurities in the water, while turbid water pumps require that the water does not contain stones and excessive sediment.
Regular sewage discharge is an important step in maintaining the normal operation of the sprinkler truck. The water storage tank of the sprinkler truck is equipped with a sewage pipe, and the inlet is at the lowest point. After using it for a period of time, the drain pipe switch should be opened regularly to drain the accumulated debris in the tank until the water becomes clear.

Conclusion: The Isuzu water tank truck has a variety of functions and features and is suitable for greening and cleaning work in various urban environments. With proper operation and maintenance, Isuzu water tank truck can provide efficient and reliable spraying effects, contributing to the improvement and beautification of the urban environment. It should be noted that the operating instructions should be strictly when using it, and the water source should be inspected and maintained to ensure the normal operation and long-term use of the sprinkler truck. By giving full play to the functions and characteristics of Isuzu sprinkler trucks, we can make greater contributions to the improvement of the urban environment.
