Isuzu NKR back loading garbage truck also known as Isuzu rear loader compactor truck, is a new type of sanitation vehicle specially used for collecting, transferring and removing garbage. Isuzu back loading garbage truck is widely used in urban cleaning, garbage disposal and transportation, etc. It solves the problem of secondary pollution in the process of garbage transportation, and has the advantages of high pressure, good sealing, easy operation and safety.
Isuzu back loading garbage truck (also called waste compactor truck, garbage compactor truck, trash compactor truck, refuse collection truck, compactor garbage truck,rubbish truck, waste collection vehicle) is designed to collect and transport municipal solid waste.
ISUZU 120hp 5cbm Isuzu rear loader compactor truck |
||
Chassis |
||
Chassis model number |
ISUZU 100P chassis(QL1040BUHACY) |
|
Cabin |
Brand: ISUZU |
|
100P single cabin, 4x2 left hand drive |
||
2 seats, with air conditioner, USB connector radio |
||
Vehicle Main Dimensions |
Overall dimensions (L x W x H) mm: 6190*1880*2320 mm |
|
Wheel base: 3360 (mm) |
||
Overhang (front/rear): 1015/1525 (mm) |
||
Approach angle: 24° |
||
Departure angle: 16° |
||
Weight in KGS |
Curb Weight:4210 kg |
|
Payload:3-5 Tons |
||
Max. driving speed(km/h) |
100 | |
Engine |
Brand |
ISUZU |
Model |
4KH1 , EURO 6 |
|
Emission |
2999 ml |
|
Type |
4-stroke direct injection,4-cylinder in-line with water cooling, turbo-charging and inter-cooling |
|
Horse Power(HP) |
120HP | |
Gearbox |
ISUZU MSB, 5 Forwards gear & 1 reverse gear |
|
Tire |
700R16, 6 pcs+1 spare tire |
|
Axle |
Front axles 2~2.5t, rear axle 4~4.8t |
|
Garbage box parameters |
||
Volume |
5 m3 |
|
Material |
Carbon steel and high tensile steel |
|
Standard equipment |
1. Dustbin volume: 5m³ 2. hydraulic control device |
Isuzu rear loader compactor truck is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing repollution. When arriving at destination, the garbage can be dumped completely.
Isuzu garbage disposal truck are highly efficient vehicles that are specifically designed for collecting and transporting waste materials. These trucks have a unique design that allows them to easily load waste materials into the rear of the vehicle, making them ideal for use in urban areas where space is limited. There are several key features of the Isuzu NKR back loading garbage truck that make it a popular choice for waste collection companies.
1. The Isuzu garbage removal truck is equipped with a hydraulic system that allows the rear loading mechanism to be easily operated by the driver.
This system makes it quick and simple for the driver to load waste materials into the back of the truck, saving valuable time and manpower. The hydraulic system also ensures that the loading process is smooth and efficient, reducing the risk of spillage or damage to the vehicle.
2. The Isuzu garbage collector truck is built with a durable and reliable chassis that can withstand the rigors of daily use in demanding environments.
Isuzu garbage collector truck is constructed from high-quality materials that are designed to last, ensuring that it can handle the heavy loads of waste materials that it will be transporting. The sturdy chassis of the Isuzu garbage collector truck also provides a stable platform for the rear loading mechanism, ensuring that it operates smoothly and efficiently.
3. The Isuzu trash compactor truck is equipped with a spacious and well-designed interior that provides ample storage space for waste materials.
Isuzu trash compactor truck is equipped with a large capacity waste bin that can hold a significant amount of waste, allowing the driver to collect and transport more waste materials in a single trip. The interior of the Isuzu trash compactor truck is also designed to be easy to clean and maintain, ensuring that the vehicle remains in top condition for years to come.
In conclusion, the Isuzu NKR back loading garbage truck is a highly efficient and reliable vehicle that is well-suited for waste collection and transportation. With its hydraulic loading system, durable chassis, and spacious interior, this truck is an ideal choice for waste collection companies looking for a versatile and dependable vehicle.
