How to use Isuzu truck

The importance of correct operating procedures for Isuzu truck with crane cannot be underestimated. As a kind of heavy equipment, the operation of Isuzu truck with crane is not only related to work efficiency, but also to personal safety and property safety. Compliance with correct operating procedures can ensure the smooth progress of lifting tasks and reduce the risk of accidents.

Correct operating procedures can improve the efficiency of Isuzu truck with crane. Accurate operating methods can save time and power consumption, improve operating efficiency during hoisting operations, and ensure timely loading and unloading of goods, which is particularly important for the logistics industry. Reasonable operating procedures can reduce duplication of work and incorrect operations, help establish good communication between truck drivers and guides, and improve operating efficiency.



Isuzu truck with crane operation steps:

1. Observe the operating environment of the Isuzu truck with crane, select a suitable angle for lifting operations, ensure there is enough space for the left and right outriggers to be fully opened, and park the truck at a suitable distance from the cargo according to the weight of the cargo.

2. Start the Isuzu truck with crane, hang up the power take-off, and put the power take-off in working condition. The specific operation is to step on the clutch, put the transmission handle in the neutral position, start the car, and observe the air pressure value when it reaches 0.5-.06Mpa. , pull out the manual air valve of the power take-off, and slowly release the clutch. At this time, the clutch is in working condition.

3. Only after completing the pre-operation inspection of the Isuzu truck with crane can the crane be used to operate the outriggers and boom.

4. Move the selector valve to the outrigger position on the sign, operate the outrigger, open the movable outrigger locking device, and extend the left and right horizontal outriggers and the left and right vertical outrigger cylinders according to the corresponding marks on the operating lever to ensure that the outriggers are Fully extended to support crane.

5. After the outrigger cylinder supports the crane, move the selector valve to the crane position on the sign, and use the crane to perform hoisting operations.



Isuzu truck with crane operating precautions:

A. Precautions during operation:

1. Before using the crane, you need to ensure that the outrigger cylinders are fully opened and the outriggers are locked. The outrigger cylinders are on the ground and the car cannot be suspended in the air. All wheels of the car must be on the ground.

2. Before turning on the power take-off, check whether the control handle is in the neutral position. If the handle is not in the neutral position, return it to the neutral position.

3. Check whether the stop valve on the hydraulic tank is open. If not, be sure to open it and check the amount of oil in the tank. The oil level must not be higher or lower than the maximum or minimum mark.

4. Ensure that the car has enough fuel to avoid power interruption during work. At the same time, check whether the battery pack is normal to ensure that it can start at any time when power interruption occurs.

5. Before using the crane, check whether the safety device of the crane is working properly.

6. Check the entire power pipeline to see if there is any oil leakage or pressure loss.



B. Precautions during operation:

1. Operating and lifting heavy objects should be on the same side to ensure proper viewing angle and safe operation.

2. Expand and use the crane correctly according to the signs corresponding to the operating levers.

3. When the hook is lowered, at least 3 turns of wire rope should be retained on the drum.

4. When the wear of the outer steel wire of the steel wire rope reaches 10% of its diameter, the steel wire rope should be scrapped.

5. Before lifting the goods, the weight of the goods must be estimated. This value must be compared with the rated load on the lifting moment, and the line from the point of descent of the goods must be calculated.



C. Precautions after operation:

1. Be sure to ensure that the movable outriggers are fully retracted, and check whether the locking assembly is locked.

2. After the work is completed, disconnect the hydraulic pump from the power take-off device. After the operation is completed, check whether each control handle is automatically reset. If the handle is not in the neutral position, return it to the neutral position.

3. Move the selector valve to the leg position on the sign.

4. Place the locking assembly lever in the open state and open the movable outrigger locking device.

5. Retract the left and right vertical legs and horizontal legs according to the operating instructions.

6. After each movable outrigger has shrunk a few centimeters, return it to the locked state, then retract the movable outrigger into position, and the locking assembly rod will automatically embed and lock.

7. Turn off the power take-off.

8. Turn off the power.
