POWERSTAR
TRUCKS manufactured and exportedISUZU road sweeper trucks many years with good reputation. Road sweeper truck also called( wet street sweeper , municipal vehicle
,washer and sweeping car , street cleaner sweeper and clean street
cleaning vehicle), is suitable for brushing , suction and transportation
of dusts,leaves,mud , soil , sand , stones, gravels and other small
particles on the ground of city roads and areas , This unit shall be
suitable for dry type clean wall as dust suppression with water spray in
the road side and narrow lanes .
The
garbage bin adopts a whole stainless-steel single-layer structure, which
is not rusty as a whole. The garbage tank adopts an inclined plate
structure, which is convenient for unloading without manual
intervention. With a variety of safety alarm devices: low water level of
the clean water tank, operation reminder, auxiliary engine water
temperature, oil pressure, reversing reminder, hydraulic oil leak alarm,
dumpster tipping, reset safety alarm, and other devices.
The
hydraulic system takes power from the chassis engine and the auxiliary
engine respectively and controls the dumping of the garbage tank, the
opening and closing of the tailgate, and the rotation of 5 cleaning
motors through the electromagnetic hydraulic valve group. When dumping
garbage, there is no need to start the auxiliary engine. The garbage
tank can be dumped and the tailgate can be opened and closed directly
through the main engine of the chassis, which is easy to operate. If the
main engine fails and the body cannot work, the auxiliary engine can be
used to realize the body movement, which is convenient for maintenance.
The original Japanese brand ISUZU 5-6cbm street sweeper lorry.Which
based on original ISUZU chassis, 4KH1CN diesel engine with 130HP, ISUZU
MSB 5-shift manual gearbox, 7.00-16tires with 6+1 units, including one
spare tire, 3360mm wheelbase as standard. equipped
with ISUZU technology auxiliary diesel engine, 4cbm dust bin and 1cbm
water bin, both material are stainless steel. equipped with powerful fan
system, 4 units sweeping booms with original import Italy brand
hydraulic motor, as for rear suction system, which can be optional with
rolling brushes or without. All
painting and logos 100% based on customer requirement.
Here
below link is
best selling model 5cbm road sweeper body kit with CCC and ISO 9001 operation Manual for guidance:
