The MORO PM70A vacuum pump is a high-performance, high-efficiency vacuum pump mainly used in industrial and commercial applications. MORO vacuum pump is driven by a powerful electric motor that can generate a vacuum flow of up to 70 l/min.

This vacuum pump is manufactured with advanced workmanship and materials to ensure its reliability and long-lasting. It has a compact design and light weight, making it easy to install and move. MORO PM70A vacuum pump has various functions and features, including automatic start-stop control, overheat protection and automatic lubrication system. It is also equipped with a multi-stage oil separator, which can effectively remove oil vapor and impurities.

In addition, it is characterized by low noise and vibration, which reduces disturbance to operators and equipment. This vacuum pump is suitable for various applications such as industrial production lines, chemical plants, medical equipment and laboratories.

MORO PM70A vacuum pump is a product with the following characteristics:

High efficiency and energy saving: MORO PM70A vacuum pump adopts advanced technology and design, and can output with lower power to achieve higher vacuum degree. It has high working efficiency, can save energy and reduce operating costs.

Multifunctional use: MORO PM70A vacuum pump has multiple functions and is suitable for different application fields. It can be used in vacuum transportation, vacuum distillation, vacuum drying and other links in industrial production. At the same time, it can also be used in laboratory research, medical equipment and other fields.

Safe and reliable: MORO PM70A vacuum pump is manufactured with high-quality materials and workmanship, and has good durability and stability. It can run stably for a long time, and only produces low noise and vibration, ensuring safety and reliability during use

Easy to operate: MORO PM70A vacuum pump is simple in design and easy to operate. It is equipped with an intuitive control panel, users can easily set up and adjust. In addition, the vacuum pump also has an automatic start-stop function, which can automatically start and stop according to needs.

Easy maintenance: MORO PM70A vacuum pump has the characteristics of easy maintenance. It is designed so that maintenance personnel can quickly access and replace parts.

In addition, the vacuum pump is also equipped with an intelligent diagnostic system, which can detect faults in time and provide corresponding solutions to reduce downtime.

It can be used in many fields such as suction, pumping and material transportation. In summary, the MORO PM70A vacuum pump is a reliable, efficient and versatile vacuum pump for a wide variety of industrial and commercial applications. Its advanced design and technology make it one of the best vacuum pumps on the market today.

MORO - Pump Model Selection Chart

Model        PM60A    PM70A    PM80A    PM110A

Free air flow (Lt/min)    lt/min    7200    9400    12000    16400
m3/h    432    564    720    984
cfm    254    332    424    579
Continuous duty vacuum    %    80%    80%    80%    80%
In Hg    23.6    23,6    23,6    23,6
Maximum vacuum    %    95%    95%    95%    95%
In Hg    28    28    28    28

Max. operating absolute press    bar abs    3    3    3    3
barg    2    2    2    2
psi abs    43,5    43,5    43,5    43,5
psig    29,0    29,0    29,0    29,0
Power required at maximum vacuum    kW    9 kW    11,5 kW    14 kW    19 kW
hp    12,2    15,6    20,4    25,8
Power required at max. pressure    kW    18 kW    26 kW    34 kW    41 kW
hp    24,5    35,4    46,2    55,7
Oil consumption    gr/h    180 gr    200 gr    220 gr    210 gr
Oil tank capacity    It    1,7 It    2,7 lt    3,7 lt    4,8 lt
Quarts    1,8    2,9    3,9    5,1
Weight    dB-A    75    76    76    80
Max. speed    rpm    1400    1400    1400    1400
Working speed    rpm    1000÷1100    1000÷1100    1000÷1100    1000÷1100
Max. speed    rpm    540    540    540    540
Working speed    rpm    450    450    450    450
