Isuzu telescoping boom crane truck also called Isuzu boom crane,Isuzu crane truck,Isuzu truck mounted crane，Isuzu mounted lifting transport truck.The vehicle is a kind of equipment that realizes the lifting, turning and lifting of goods through a hydraulic lifting and telescopic system. It is usually installed on a truck. It is generally composed of truck chassis, crane, subframe, cargo compartment and power take-off device. It is widely used in various occasions, such as high-altitude operations, bridge maintenance, wood handling, bulk cargo shipping and traffic accident rescue, etc. It is a commonly used multi-functional engineering special vehicle.

The Isuzu telescoping boom crane series truck crane is installed between the cab and the carriage. When the vehicle is operating, power is taken from the gearbox in the cab to drive the hydraulic pump to rotate. High-pressure oil is provided to each component to enable the straight-arm crane to move in various directions on the truck-mounted crane.

The boom of an Isuzu telescoping boom crane usually consists of a fixed arm and several telescopic arms. Usually there are only 2 or 1 telescopic arm. The extension and retraction of the telescopic arm are driven by hydraulic cylinders. The extension and retraction of the multi-section telescopic arm are Retraction relies on the joint action of a hydraulic cylinder and a wire rope installed inside the boom. The first two telescopic arms extend and retract in sequence, and the telescopic arm pulled by the wire rope extends and retracts at the same time.

The Isuzu telescoping boom crane truck′s boom has a long boom and a long hydraulic cylinder stroke. The straight arm has a wider range of applications, is smoother and safer.
