How to use Isuzu truck

POWERSTAR TRUCKS produced and export ISUZU ELF 8000liters hook lift garbage truck Upper assembly road, which also called Isuzu pull arm hydraulic lifter garbage truck, Hydraulic arm removable carriage garbage truck, Hook lifter garbage truck, Hook loader garbage vehicle: the volume of the car body is 5 cubic meters, which is made of carbon steel plate, the interior is made of anti-rust, hydraulic pump, multi-way valve, the car can be unloaded, the cab can be operated, and other factories are standard. A set of pull arm hook loading system is adopted, and the pull arm hook swings through the expansion and contraction of the oil cylinder to complete the hook loading, hook unloading and unloading of the sealed garbage bin.One year warranty for three key parts (engine ,gear-box, axle).

The original Japanese ISUZU ELF 8CBM hook loader trucks are use ISUZU 190HP diesel engine, MLD 6-shift manual gearbox, 3815mm wheelbase, 235/75R17.5 tire with 6+1 units, The hook arm made of national standard carbon steel plate Q345, the thickness of the plate is 6MM, and garbage bins volume is 8 square meters, with uncovered bins and sealed bins optional. Garbage bin loading time Less than 15 seconds, garbage bin unloading time Less than 15 seconds, garbage discharge time Less than 10 seconds. Roller material Cast iron or forged steel, Control method Electronic control + manual matchable working, Operating position Cab + car side, all painting and logos 100% based on customer requirement.

Here below link is Original JAPANESE ISUZU mini ELF 8000L Carriage Removable Garbage Truck operation Manual for guidance:

https://www.dumperlorry.site/uploadfile/news/ISUZU%20Hook%208CBM%20%20Loader%20Truck%20Manual%20export%20Mongolia.pdf
