ISUZU FVR 5X 240HP cargo truck chassis for vacuum truck
ISUZU FVR 5X 240HP cargo truck chassis for vacuum truck
July 24, 2024
ISUZU FVR cargo truck chassis is a truck chassis produced by Qingling Motors Co., Ltd., with the following main features: Chassis type: Isuzu FVR cargo chassis mounted with GIGA 5X cabin belongs to the second category chassis, suitable for all kinds of special trucks. Emission standards: The emission standards of FVR truck chassis vary according to different models and manufacturing years, and right now meet the National VI B or EURO 6 stage of emission. Number of axles and tires: Isuzu FVR truck chassis are usually designed with 2 axles and equipped with 6 tires, front single tyre and rear double tyres, tyre can be standard 295/80R22.5 tubeless model.
Engine parameters for ISUZU GIGA 5X cargo truck chassis: Engine model: Most of them use diesel engines produced by Qingling Motors Co., Ltd., such as 6HK1-TC model. Engine displacement: Taking 6HK1-TC as an example, its engine displacement is 7790CC. Engine power: The power varies depending on the engine model and emission standards. For example, the standard with 6HK1-TCG61 engine has an engine power of 240HP, while the 6HK1-TCG60 engine with emissions reaching National VI B stage has an engine power of 300 horsepower.
Dimensions and weight for ISUZU 240HP cargo truck chassis: Chassis wheelbase: The ISUZU FVR truck chassis can be customized to build different type upper body kits, so the wheelbase can be customized as 4500mm, 5550mm, 6300mm, 7150mm. Curb weight and total mass: Curb weight and total mass vary depending on the specific model and configuration. For some normal truck chassis, the total gross vehicle weight is 18000 kg; For some special truck chassis to be build fire trucks, which have design total gross vehicle weight is 22000 kg.
Application field: ISUZU FVR GIGA 5X truck chassis is widely used in special fields such as logistics, including Isuzu freezer truck, Isuzu cargo truck, Isuzu dropside truck, etc. Also for fire fighting and rescue, such as Isuzu fire truck, Isuzu manlifter truck, Isuzu boom crane truck, Isuzu rotator wrecker truck, etc. Also can be used for military, Including Isuzu cooking truck, Isuzu camping trucks, Isuzu offroad trucks, etc. Due to its excellent cost performance and reliability, Isuzu FVR GIGA 5X cargo trucks are very popular and durable for service.
