Brand new of Isuzu ELF 100p 6wheeler cabin chassis truck, also called as Isuzu single cabin truck chassis or Isuzu garbage truck chassis cabin, it's available for Isuzu garbage compactor truck, Isuzu fuel water tanker truck, Isuzu manlifter truck, Isuzu cargo truck with crane, and so on.
Specification
| China 100P/ELF 6 Wheeler 120HP LIGHT TRUCK CHASSIS | ||
| Vehicle Parameters |
Vehicle Model: | QL1040 |
| Overall Dimension(L x W x H) | 4605x1695x2105mm | |
| Curb Weight: | 1680Kg | |
| GVW: | 4200Kg | |
| Wheelbase: | 2490mm | |
| Drive Type: | 6 Wheeler (4 wheeler also available) | |
| Engine | Engine Model: | 4KH1CN6LB, Euro4,5,6 |
| Engine type: | 4-cylinder in-line with water cooled, turbo-charging and intercooler,high pressure common rail 1600 Bar | |
| Engine Power: | 88Kw | |
| Displacement: | 2.999L | |
| Horsepower: | 120Ps | |
| Max. Torque | 220N.m/1700rpm | |
| Addblue | No need | |
| Transmission | Transmission: | MSB-5SM, Manual |
| Forward Gear: | 5 Speed Gear | |
| Backward Gear: | 1 Speed Gear | |
| Seats | Front Seat: | 2 |
| Cabin | 100P Cabin, single row. 1695mm width.Tilting cabin | |
| Chassis | Front Wheel Distance: | 1385mm |
| Rear Wheel Distance: | 1395mm | |
| Axle Loads: | Double Axles | |
| Rear axle ratio: | 5.571, (6.142 option) | |
| Tires: | 6pcs with one spare tire | |
| Tire Model: | 7.00R15 10PR | |
| Standard configuration | 1 | Power Steering |
| 2 | AC | |
| 3 | Retro-reflective Marking | |
| 4 | ABS | |
| 5 | Free Maintenance Battery | |
| 6 | Single tire in the rear | |
